Certification: CE,Rohs,EMC

 *Each pixel control



Input Voltage ： AC100V~AC240V， 50/60Hz；
Power Consumption ： 180W；
Lamp Specifications ：18 pcs four in one（RGBW) high-efficiency 10W LED, rated life 50000 hours；Lens Angle：25o（optional：45 °）；
Spot Angle：40o；

Color：RGBW linear color mixing；
Color Temperature： color cast calibration setting 、 color temperature output inside device；
Dimmer： 0-100% linearly dimming ，
5 dimmer modes:32-bits dimming, still keep smooth dimming when changing at the range of low DMX value;
Refresh Frequency:1800Hz, no blink when camera shooting;

Shutter： independent electronic strobe ；

Control Mode：

Standard DMX512，3 pin interfaces ；

5 Channel modes；

Master/slave mode，no need to set up the master and slave manually, will receive the main engine data automatically ；

33 auto-running modes，rainbow channel,  rainbow effect  and flow water effect；

Other Functions：

Self-programming function, 3 chases，each chase has 25 scenes，fade function;

Projector setting data、self-programming data can be downloaded each other ；

Temperature Control Protection ： lamp body  temperature control protection ；

Waterproof Grade ： IP20

Work Environment Temperature ： -20°C～40°C；

Net Weight:5.0kgs
